Descripción
Intelligent Analytics
AI By Device = Facial recognition, perimeter protection, motion detection 2.0
AI By Camera = Facial recognition, perimeter protection, throwing objects from building, motion detection2.0, ANPR, VCA
Facial Recognition
Atributos Faciales = N/A
Facial Detection And Analytics = Face picture comparison, human face capture, face picture search
Face Picture Library = Up to 16 face picture libraries, with up to 5,000 face pictures in total (each picture ≤ 1MB, total capacity ≤ 73MB);Up to 16 face picture libraries, with up to 20,000 face pictures in total (each picture ≤ 4 MB, total capacity ≤ 1 GB)
Facial Detection And Analytics Performance = 1-ch, 4 MP;1-ch, 8 MP
Face Picture Comparison (Captured From Camera) = 2-ch
Detección De Movimiento 2.0
By Device = All channels, 4 MP (when enhanced SVC mode is enabled, up to 8 MP) video analysis for human and vehicle recognition to reduce false alarm
By Camera = All channels
Protección Perimetral
By Device = 1-ch, 4 MP (HD network camera, H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm
By Camera = All channels
Video And Audio
Entrada De Vídeo IP = 4-ch
Incoming Bandwidth = 40 Mbps
Outgoing Bandwidth = 80 Mbps
HDMI Output = 1-ch, 4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
VGA Output = 1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
Video Output Mode = HDMI1/VGA simultaneous output
CVBS Output = N/A
Salida De Audio = 1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio = 1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input)
Descodificación
Formato De Decodificación = H.265/H.265+/H.264+/H.264
Resolución De Grabación = 12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Reproducción Sincrónica = 4-ch
Decodificación = AI on: 1-ch@12 MP (30 fps)/1-ch@8 MP (30 fps)/3-ch@4 MP (30 fps)/6-ch@1080p (30 fps)
AI off: 1-ch@12 MP (30 fps)/2-ch@8 MP (30 fps)/4-ch@4 MP (30 fps)/8-ch@1080p (30 fps)
Stream Type = Video, Video & Audio
Compresión De Audio = G.711ulaw/G.711alaw/G.722/G.726/AAC
Red
Conexión Remota = 128
API = ONVIF (profile S/G); SDK; ISAPI
Compatible Browser = IE11, Chrome V57, Firefox V52, Safari V12, Edge V89, or above version
Protocolo De Red = TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
Interfaz De Red = 1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
PoE
Interfaz = 4, RJ-45 10/100 Mbps self-adaptive Ethernet interface
Alimentación = ≤ 50 W
Estándar = IEEE 802.3af/at
Auxiliary Interface
SATA = 1 SATA interface
Capacidad = Up to 10 TB capacity for each HDD
Interfaz USB = Front panel: 1 × USB 2.0; Rear panel: 1 × USB 2.0
Alarma E/S = 4/1;N/A ;N/A (4/1 is optional)
General
GUI Language
English, Russian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Turkish, Japanese, Danish, Swedish Language, Norwegian, Finnish, Korean, Traditional Chinese, Thai, Estonian, Vietnamese, Croatian, Slovenian, Serbian, Latvian, Lithuanian, Uzbek, Kazakh, Arabic, Ukrainian, Kyrgyz , Brazilian Portuguese, Indonesian
Fuente De Alimentación = 48 VDC, 1.35 A
Consumo = ≤ 10 W (without HDD and PoE off)
Temperatura De Trabajo = -10 °C to 55 °C (14 °F to 131 °F)
Condiciones De Humedad = 10% to 90%
Dimensión (W × D × H) = 320 mm × 240 mm × 48 mm (12.6″× 9.4″ × 1.9″)
≤ 1 kg (without HDD, 2.2 lb.)
Certificación
CE
EN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035: 2017
Obtained Certification
CE, FCC, IC, CB, KC, UL, Rohs, Reach, WEEE, RCM, UKCA, LOA, BIS;CE, CB, KC, Reach, WEEE, RCM, UKCA, LOA
