Descripción
Intelligent Analytics
AI By NVR = Facial recognition, perimeter protection, video structuralization, throwing objects from building
AI By Camera = Facial recognition, perimeter protection, video structuralization, throwing objects from building, motion detection2.0, ANPR, people counting, VCA
Engine = 1 engine can run an intelligent algorithm, engine mode is adjustable
Facial Recognition
Facial Detection And Analytics = Face picture comparison, human face capture, face picture search
Face Picture Library = Up to 16 face picture libraries, up to 100,000 face pictures in list library, up to 10,000 face pictures in stranger library, up to 5,000,000 face pictures in face capture (each picture ≤ 4 MB, total capacity ≤ 20 GB)
Face Picture Comparison (Captured From Camera) = 16-ch;
Comparison speed: 24 pictures per second
Facial Detection And Analytics Performance = 8-ch 2 MP, up to 8 MP
Perimeter Protection
By NVR = 12-ch 2 MP, up to 8 MP
By Camera = All channels
Video Structuralization
Structured Analysis = 6-ch 2 MP, up to 8 MP
Face Picture Library = Up to 32 face picture libraries, up to 100,000 face pictures in list library, up to 10,000 face pictures in stranger library, up to 500,000 face pictures in face capture (each picture ≤ 4 MB, total capacity ≤ 20 GB)
Face Picture Comparison = 8-ch;
Comparison speed: 16 pictures per second
Throwing Objects From Building
By NVR = 8-ch 2 MP, up to 8 MP
By Camera = All channels
ANPR
By Camera = All channels
Plate Attributes = Vehicle brand, vehicle color, vehicle type
Vehicle Attributes = Plate number, license plate color, license plate type
Video And Audio
IP Video Input = 16-ch
Up to 32 MP resolution
*: After ultra HD resolution mode is enabled, the NVR supports up to 8-ch 32 MP/24 MP IP video inputs.
Incoming Bandwidth = 256 Mbps
Outgoing Bandwidth = 256 Mbps
HDMI Output = 8K (7680 × 4320)/30Hz, 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
VGA Output = 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Video Output Mode = HDMI/VGA independent output
CVBS Output = 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
Audio Output = 1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio = 1-ch, RCA (2.0 Vp-p, 1 k Ω)
Decoding
Decoding Format = H.265/H.265+/H.264/H.264+
Decoding Capability = 2-ch@32 MP (30 fps)/2-ch@24 MP (30fps)/4-ch@16 MP (30fps)/8-ch@8 MP (30fps)/16-ch@4 MP (30fps)
Synchronous Playback = 16-ch
Recording Resolution = 32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/ 2CIF/CIF/QCIF
*: After ultra HD resolution mode is enabled, the NVR supports up to 8-ch 32 MP/24 MP IP video inputs.
Network
Remote Connection = 128
Network Protocol = TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
API = ONVIF (profile S/G); SDK; ISAPI
Compatible Browser = IE11, Chrome V57, Firefox V52, Safari V12, Edge V89, or above version
Network Interface = 1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
PoE
Interface = 16 RJ-45 10/100 Mbps self-adaptive Ethernet interfaces
Power = ≤ 200 W
Standard = IEEE 802.3 af/at
Auxiliary Interface
SATA = 2 SATA interfaces; 3.5-inch HDD
ESATA = 1 eSATA interface
Capacity = Up to 14 TB capacity for each HDD
USB Interface = Front panel: 1 × USB 2.0; Rear panel: 1 × USB 3.0
Alarm In/Out = 4/1
General
GUI Language
English, Russian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Turkish, Japanese, Danish, Swedish Language, Norwegian, Finnish, Korean, Traditional Chinese, Thai, Estonian, Vietnamese, Croatian, Slovenian, Serbian, Latvian, Lithuanian, Uzbek, Kazakh, Arabic, Ukrainian, Kyrgyz , Brazilian Portuguese, Indonesian
Power Supply = 100 to 240 VAC, 50 to 60 Hz
Consumption = ≤ 50 W (without HDD and PoE off)
Working Temperature = -10 to 55° C (14 to 131° F)
Working Humidity = 10 to 90%
Dimension (W × D × H) = 385 × 315 × 52 mm ( 15.2″× 12.4″ × 2.0″)
Weight = ≤ 3 kg (without HDD, 2.2 lb.)
Certification
Obtained Certification
CE, FCC, IC, CB, KC, UL, Rohs, Reach, WEEE, RCM, UKCA, LOA, BIS
FCC
Part 15 Subpart B, ANSI C63.4-2014
CE
EN 55032:2015+A1:2020, ENIEC61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:201
9, EN 50130-4:2011+A1:2014, EN 55035:2017+A11:2020
