Descripción
Cámara
Sensor De Imagen = 1/2.4″ Progressive Scan CMOS
Max. Resolución = 3200 × 1800
Iluminación Mínima = Color: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR
Tiempo De Obturación = 1/3 s to 1/100,000 s
Día Y Noche = IR cut filter
Ajuste De Ángulo = Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360°
Lente
Lente = Fixed focal lens, 2.8 and 4 mm optional
Focal Length & FOV = 2.8 mm, horizontal FOV 105°, vertical FOV 55°, diagonal FOV 127° / 4 mm, horizontal FOV 78°, vertical FOV 38°, diagonal FOV 96°
Montura Del Lente = M12
Iris Type = Fixed
Apertura = F1.6
DORI
DORI = 2.8 mm, D: 76 m, O: 30 m, R: 15 m, I: 7 m / 4 mm, D: 115 m, O: 45 m, R: 23 m, I: 11 m
Iluminador
Tipo De Luz Suplementaria = IR,White Light
Rango De Luz Suplementaria = IR: up to 30 m / White Light: up to 20 m
Luz De Suplemento Inteligente = Yes
IR Wavelength = 850 nm
Vídeo
Main Stream = 50 Hz: 20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-Stream
50 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360)
Compresión De Video
Main stream: H.265+/H.265/H.264+/H.264,
Sub-stream: H.265/H.264/MJPEG
Vídeo Bitrate = 32 Kbps to 16 Mbps
Tipo H.264 = Baseline Profile,Main Profile,High Profile
Tipo H.265 = Main Profile
Bit Rate Control = CBR,VBR
Región De Interés (ROI) = 1 fixed region for main stream
Audio
Tipo De Audio = Mono sound
Filtro De Ruido Ambiental = Yes
Frecuencia De Muestreo De Audio = 8 kHz/16 kHz
Compresión De Audio = G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC
Velocidad De Bits De Audio = 64 Kbps (G.711ulaw)/64 Kbps (G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)
Red
Seguridad = Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)
Vista En Vivo Simultánea = Up to 6 channels
API = Open Network Video Interface (Profile S, Profile T, Profile G (only -F model supports)),ISAPI,SDKProtocolos = TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP
Usuario/Operador = Up to 32 users
3 user levels: administrator, operator, and user
Cliente
iVMS-4200,Hik-Connect
Navegador Web
Plug-in required live view: IE 10, IE 11,
Local service: Chrome 57.0+, Firefox 52.0+
Imagen
Wide Dynamic Range (WDR) = 120 dB
SN = ≥ 52 dB
Interruptor Día/Noche = Day,Night,Auto,Schedule
Mejora De La Imagen = BLC,HLC,3D DNR
Configuración De Imagen = Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
Máscara De Privacidad = 4 programmable polygon privacy masks
Interfaz
Ethernet Interface = 1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage = -F: Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB
Micrófono Incorporado = Yes
Reset Key = -F: Yes
Evento
Evento Básico = Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
Linkage = Upload to FTP/memory card (-F), send email, notify surveillance center, trigger recording (-F), trigger capture
General
Alimentación
12 VDC ± 25%, 0.41 A, max. 5 W,Ø5.5 mm coaxial power plug,reverse polarity protection, PoE: IEEE 802.3af, Class 3, max. 6.5 W
Material
Metal & Plastic
Dimensión = 170.8 mm × 66 mm × 69.1 mm (6.7″ × 2.6″ × 2.7″)
Dimensión Del Paquete = 216 mm × 121 mm × 118 mm (8.5″ × 4.8″ × 4.6″)
Approx. 285 g (0.6 lb.) = Con Peso Del Paquete
Approx. 481 g (1.1 lb.) = Condiciones De Almacenaje
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Condiciones De Inicio Y Funcionamiento = -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Idioma = English, Ukrainian
Función General
Heartbeat,anti-banding,mirror,password protection,password reset via email
Certificaciones
EMC
CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014,
RCM: AS/NZS CISPR 32: 2015,
IC: ICES-003: Issue 7
Seguridad
UL: UL 62368-1,
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017,
BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005
Ambiente
CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006
Protección
IP67: IEC 60529-2013
